SSH connections to my CRS326 office switch took 5.5 seconds. Every other RouterOS device on my network connected in under half a second. The difference was noticeable enough to slow down management tasks, and it didn’t make sense.

This is the story of tracking down why one switch behaved differently, the tests that ruled out obvious causes, and what we learned about RouterOS and Marvell switch SoCs.

What Was Broken

The problem was simple: SSH connections to the CRS326 office switch at switch.lan took approximately 5.5 seconds to establish. Other RouterOS devices connected instantly.

I measured it using a simple command:

time ssh [email protected] "/system identity print"

The results were stark:

Device	Model	RouterOS	CPU	SSH Time	Status
Office Router	RB4011iGS+RM	7.19.2	4x @ 1400MHz ARM	0.106s	✅ Fast
Living Room Switch	RB960PGS (hEX PoE)	7.18.2	1x @ 800MHz MIPS	0.398s	✅ Acceptable
Office Switch	CRS326-24G-2S+RM	7.20.2	1x @ 800MHz ARM	5.5s	❌ Slow

The CRS326 was 55x slower than the router and 14x slower than a less powerful switch. Something was clearly wrong.

What Looked Right

At first glance, everything seemed normal. The switch was running RouterOS 7.20.2, the latest stable release. SSH service was enabled and configured identically to the other devices. Network connectivity was fine - no packet loss, no connection issues. The switch functioned correctly, it was just slow to accept SSH connections.

WinBox connected immediately, which ruled out network-level problems. The issue was specific to SSH.

Where The Delay Occurred

I needed to understand when the delay happened. SSH verbose logging showed the answer:

ssh -vvv [email protected]

The timeline was revealing:

• TCP connection established immediately
• Key exchange completed normally
• SSH banner received
• 5.5 second delay between SSH2_MSG_SERVICE_ACCEPT and authentication methods response
• Delay happened before user authentication even began

The delay was server-side, on the CRS326 itself, not network-related. The switch was taking 5.5 seconds to process something between accepting the SSH service and responding with available authentication methods.

Both password and public key authentication showed the same delay, which ruled out SSH key lookup as the cause. The problem was deeper in the SSH service initialization.

Hypothesis One: DNS Lookup Delay

My first hypothesis was reverse DNS lookup. RouterOS might be trying to resolve the client’s IP address, and if that lookup was timing out or taking too long, it could explain the delay.

I checked the DNS configuration on the CRS326:

/ip dns print
servers: 10.0.20.12,10.0.20.13

Internal Pi-hole servers. I tested DNS resolution times:

[[email protected]] > /tool dns query address=1.1.1.1 server=10.0.20.12
  address: 10.0.20.12
  status: ok
  time: 10ms

DNS queries completed in 10-40ms. Fast enough.

I tried several DNS-related changes anyway:

• Reduced DNS timeouts: query-server-timeout=500ms, query-total-timeout=1s
• Added static DNS entries for my client IP
• Changed to public DNS servers (1.1.1.1, 1.0.0.1)

No improvement. DNS was not the cause.

Hypothesis Two: Configuration Differences

Maybe there was a configuration difference causing the delay. I compared the CRS326 to the fast RB960PGS switch:

• Bridge configuration: Identical (single bridge, VLAN filtering enabled, fast-forward enabled)
• SSH service settings: Identical
• RouterOS version: Same 7.19.2 stable (at the start of investigation)
• Network topology: Direct connection, no relays

No configuration differences that would explain a 5.5 second delay.

Hypothesis Three: Hardware Limitations

The CRS326 specs looked reasonable:

• CPU: 1x ARM @ 800MHz
• Memory: 512MB
• CPU load: 1-3% (low load)

But the comparison was interesting. The RB960PGS has:

• CPU: 1x MIPS @ 800MHz (less powerful single-core)
• Memory: 128MB (less memory)

The RB960PGS was less powerful but 14x faster at SSH connections. Raw CPU power wasn’t the issue.

The RB4011 router has:

• CPU: 4x ARM @ 1400MHz (more powerful)
• Memory: 1GB

55x faster than the CRS326 despite similar ARM architecture. Something specific to the CRS326 was causing the delay.

The RouterOS Update Test

I upgraded to RouterOS 7.20.2 to see if a newer version fixed it. The changelog didn’t mention SSH performance, but it was worth trying.

No improvement. Still 5.5 seconds.

Beta Testing

RouterOS 7.21beta5 had SSH refactoring in the changelog. I tested it, hoping the refactor would address the performance issue.

Still 5.5 seconds. The SSH refactoring didn’t help.

What The Evidence Showed

This was clearly a CRS326-specific issue with RouterOS 7.x. The evidence pointed to something beyond configuration, DNS, or simple CPU performance:

• RB960PGS (less CPU, less memory, older bootloader 6.48.7) is 14x faster
• RB4011 (more CPU, newer bootloader 7.15.2) is 55x faster
• RouterOS 7.20.2 update: No improvement
• RouterOS 7.21beta5: Still 5.5s despite SSH refactor
• Not DNS, not CPU power, not memory, not configuration, not bootloader version

The CRS326 uses a Marvell 98DX switch SoC, while the RB4011 and RB960PGS are CPU-based devices. The delay was happening during SSH service initialization, likely in the crypto subsystem.

The Reported Root Cause

MikroTik reported that CRS3xx units running RouterOS 7.19-7.20 experience a 5-6 second SSH delay caused by crypto subsystem initialization on Marvell 98DX switch SoCs. They stated the bug doesn’t appear on CPU-based devices like the RB4011 or RB960PGS.

However, this doesn’t match what I observed in testing. The delay happened on every single SSH connection, not just the first one. If it were a one-time initialization delay, subsequent connections in quick succession should have been fast, but they weren’t. Every connection took the full 5.5 seconds, consistently.

I can’t confirm MikroTik’s explanation matches the actual root cause. The platform-specific nature (Marvell 98DX switch SoC vs CPU-based devices) aligns with my observations, but the reported mechanism doesn’t explain why the delay occurred on every connection rather than just during initialization.

The Workaround: SSH ControlMaster

I needed a workaround while waiting for a fix. SSH ControlMaster creates a persistent connection that subsequent commands can reuse:

# Start master SSH session
ssh -M -S ~/.ssh/control-%r@%h:%p -fnNT [email protected]

# Subsequent commands reuse the same session (instant)
ssh -S ~/.ssh/control-%r@%h:%p [email protected] "/system resource print"

This works for:

• Manual SSH commands
• Ansible playbooks (configure ControlPath in ~/.ssh/config)
• Any automation requiring multiple SSH connections

The first connection still takes 5.5 seconds, but every subsequent command is instant. For management workflows that involve multiple SSH commands, this makes a huge difference.

In practice, I never bothered to set up ControlMaster. I mostly just used WinBox for CRS326 management instead. WinBox connects immediately since it uses a different protocol that doesn’t trigger whatever delay was affecting SSH. For the occasional SSH command, I just waited out the 5.5 seconds.

The Update

Weeks later, after updating to RouterOS 7.20.6, the issue appears to be resolved. SSH connections now complete in under 0.2 seconds:

time ssh [email protected] "quit"
ssh [email protected] "quit"  0.02s user 0.00s system 11% cpu 0.177 total

I’m not certain the RouterOS update was the actual fix. Between documenting the bug, testing different versions, and working on other projects over those weeks, there were changes to the network environment. The timing suggests 7.20.6 fixed it, but I can’t rule out other factors that changed in the meantime.

What I can say: The CRS326 SSH performance is now normal, matching the other RouterOS devices on the network.

Lessons Learned

This bug looked like a configuration or network problem at first. It wasn’t.

• When one device behaves differently, compare systematically. Hardware differences (switch SoC vs CPU-based) can cause platform-specific bugs.

• Methodical elimination helps. Testing DNS, configuration, and hardware systematically ruled out obvious causes and pointed to the platform-specific issue.

• SSH verbose logging reveals where delays occur. Knowing the delay happened before authentication ruled out key lookup and pointed to service initialization.

• Vendor reports can be helpful but don’t always match reality. MikroTik reported the Marvell 98DX crypto bug, but the mechanism they described didn’t match what I observed in testing. It’s worth validating vendor explanations against actual behavior.

• Sometimes the simplest workaround is to use a different tool. WinBox worked fine for CRS326 management, so I didn’t bother setting up SSH ControlMaster.

• Platform architecture matters. Switch SoCs have different characteristics than general-purpose CPU-based devices. Bugs can be platform-specific even within the same RouterOS version.

What’s Next

The CRS326 is working normally now. SSH performance matches other RouterOS devices, making management tasks fast again. I’ll continue monitoring, but the issue appears resolved.

If you’re experiencing similar SSH delays on CRS3xx switches, try RouterOS 7.20.6 or later. The Marvell 98DX crypto initialization bug seems to be fixed in recent releases.

For management workflows, SSH ControlMaster remains a useful technique for reducing connection overhead, even on fast devices. It’s especially valuable for automation and Ansible playbooks that make multiple SSH connections.
